Currently only available in SB and LB models:
SB - Standard Bails - Provide ample room for attaching a line while keeping weight and overall shackle length to a minimum. Ideal for halyards and sheets.
LB - Large Bails - Provide room for up to three additional shackles or a combination of shackles and lines. Ideal for spinnaker sheets, guys or other multi-line applications.
CB - Clevis Bails - Do not require splicing and provide moveable attachments to rings, deck fittings, furlers, rolling furlers, etc. Ideal for many uses.
|Model||A||B||C||D||E||Thickness||Weight||Work Load||Break Load|
|T16 SB||23.0mm||22.2mm||19.8mm||21.4mm||119.9mm||13.2mm||258gm||3628 kg||7257 kg|
|T16 LB||23.0mm||22.2mm||33.3mm||35.7mm||136.5mm||13.2mm||360gm||3628 kg||7257 kg|
