Optolamp NAV XXI PLUS 2 - LED Navigation Light

Price:114.88 ex. VAT
Price: 139.00 (inc. VAT)
OPTOLAMP 015 NAV XXI
8 in stock
14 days (approx.)
+
Shipping Costs:

Optolamp NAV XXI Plus Tri-Colour LED Navigation Light

The development and design of the OPTOLAMP® product line was based on the requirements of round the world sailing events such as the Vendee Globe and Route du Rhum,  where low energy consumption and reliability in all weather conditions is essential.

The Electronic Controller Circuit is sealed for life by encapsulation in resin providing moisture, shock and vibration proofing for the life of the unit. Maximum Light intensity is achieved even with discharged batteries. Maximum stable light intensity within a voltage range from 10.6V to 14,4V and a reduced output as low as 9.5V. It can work approximately 35 nights with a 12V/75A battery. The latest generation of electronic circuit protects against tension peaks in the boat’s electrical system as well as reverse polarity. A photo sensitive cell switches on-off automatically at dawn, at night and during storms or fog. Simple installation with low gauge wire.

Technical Information:

  • Height: 135 mm
  • Weight: 235 grams
  • Installation base: Anodized Aluminium (60mm x 80mm)
  • Power source: 10,6V to 14,4V (Option: 24V)
  • Consumption: (12V) UBC® Ultra Low Consumption -  0,180A (180mA)
  • Light source: Electronic emission
  • LED-Lamp Life: 50000 Hs
  • Lens: Polycarbonate, UV protection
  • Horizontal Range: 2,0 NM
  • Maximum Light intensity: between 10,6V and 14,4V (start at 9,5V)
  • Maintenance free: Led lights don’t have a filament to break or burnt out
  • Fully sealed for life. Shock and Vibration proof. WARRANTY: 2 years
OPTOLAMP 24V ADAPTER
37.19 ex. VAT   45.00
24 Volt power adapter for the Optolamp Amazonia, Sirius & NAV XXI LED navigation lights. Allows the lights to be connected to 24 volts systems.
In stock
+

BLUE SEA SYSTEMS 4150
6.98 ex. VAT   8.45
Manufactured by Carling Technologies for use in Blue Sea Systems' WeatherDeck™ Panels and also suitable for isolated installation on any panel / surface up...
In stock


BLUE SEA SYSTEMS 4138
4.79 ex. VAT   5.80
Waterproof boot / cover for use with Carling Technologies and Blue Sea Systems Weatherdeck toggle switches. Once installed the switch is waterproof, rated...
In stock
+

MAST MS040404
17.77 ex. VAT   21.50
Have you ever struggled to reach the highest reef point or the top of the sail cover? Do you dread going up the mast, or winching somebody else up?  Well...
In stock


MASTWALKER TYPE A
24.75 ex. VAT   29.95
Incredibly strong folding solid alloy mast step, can withstand a 318 kg tip load.  No corrosion due to electrolysis, does not rattle, folds flat to the...
Please Confirm


Optolamp NAV XXI Installation Manual EN (Optolamp_Nav_XXI_Instalation_Manaul_EN.pdf, 46 Kb) [Download]
